QDB-3A Ignition Coil Tester, Drive Automobile Ignition Coil Tester Tool, Injector Solenoid Valve Tester, for Idling Stepper Motor Automobile Fault Detector, 1.8” Color Display
4.0 (140 items)
Limited Time SaleUS$24.04 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211811509 | Release Date | 2026/04/04 | List Price | US$16.03 | Model Number | 211811509 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
QDB-3A Ignition Coil Tester, Drive Automobile Ignition Coil Tester Tool, Injector Solenoid Valve Tester, for Idling Stepper Motor Automobile Fault Detector, 1.8” Color DisplayTest Capabilities: Ignition coil tester can directly test 12V-24V gasoline/natural gas engine ignition coils, gasoline/diesel vehicle injectors (excluding piezo injectors), duty cycle-controlled motors, solenoid valves, low-power stepper motors, etcDuty Cycle Simulation: Ignition coil tester tool can accurately simulate duty cycle sensor signals, providing precise testing for various automotive componentsAdjustable Hall Signal: Ignition coil tester features adjustable output frequency, amplitude and duty cycle ratio to simulate various duty cycle sensors, including air conditioning pressure sensors and air flow metersWide Range: Ignition coil tester offers electromagnetic coil driving current adjustable 0-3.5A, output frequency 1Hz-100kHz, and duty cycle adjustment 1%-100% to meet diverse testing needsSafety Protections: Built-in reverse connection and over-current protections ensure safe operation during testing, making the ignition coil tester tool compatible with a wide variety of vehiclesUser-Friendly: All parameters of the ignition coil tester tool are easily adjustable, allowing for simple operation, perfect for automotive professionals and DIY enthusiasts alikeSPECIFICATIONPower input: 9-26V, 100WPower output: Max 2.5AVADJ output: 1.25-14.5V, max 1.5APWM drive: 1-100KHz, 0-100% duty, max 3APWM signal: 1-100KHz, 0-100% duty, 1.25-14.5V VPPStep motor: Max 1.5AOperating temperature: 0-55℃Dimensions: 6.18x3.82x1.18 inPACKAGE1 x Ignition Coil Tester1 x Power Cable3 x Test Connection Cables3 x Single Plugs1 x Idle Speed Stepper Motor Plug1 x Stepper Motor Welding Cable
- Test Capabilities: Ignition coil tester can directly test 12V-24V gasoline/natural gas engine ignition coils, gasoline/diesel vehicle injectors (excluding piezo injectors), duty cycle-controlled motors, solenoid valves, low-power stepper motors, etc
- Duty Cycle Simulation: Ignition coil tester tool can accurately simulate duty cycle sensor signals, providing precise testing for various automotive components
- Adjustable Hall Signal: Ignition coil tester features adjustable output frequency, amplitude and duty cycle ratio to simulate various duty cycle sensors, including air conditioning pressure sensors and air flow meters
- Wide Range: Ignition coil tester offers electromagnetic coil driving current adjustable 0-3.5A, output frequency 1Hz-100kHz, and duty cycle adjustment 1%-100% to meet diverse testing needs
- Safety Protections: Built-in reverse connection and over-current protections ensure safe operation during testing, making the ignition coil tester tool compatible with a wide variety of vehicles
- User-Friendly: All parameters of the ignition coil tester tool are easily adjustable, allowing for simple operation, perfect for automotive professionals and DIY enthusiasts alike
| UPC | 768795954730 |
|---|---|
| Color | multi |
| Model | QDB-3A |
| Brand Name | RQG |
| Style Name | QDB-3A |
| Manufacturer | RQG |
| Power Source | Corded Electric |
| Included Components | Ignition Coil Tester, Cables, Plugs |
| Upper Temperature Rating | 55 Degrees Celsius |
| Minimum Operating Voltage | 9 Volts |
